2-328394-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2-328394-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2-328394-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2-328394-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN SPADE TERM 16-22AWG #2 RED |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 5000 pcs | ||||
|---|---|---|---|---|---|
| $0.127 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2-328394-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN SPADE TERM 16-22AWG #2 RED | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 154302 pcs | Data sheet | 328394 |
| Category | Connectors, Interconnects | Wire Gauge | 16-22 AWG |
| Width - Outer Edges | 0.182" (4.62mm) | Tongue Inside Opening | 0.093" (2.36mm) |
| Termination | Crimp | Terminal Type | Standard |
| Stud/Tab Size | 2 Stud | Series | PIDG |
| Packaging | Tape & Reel (TR) | Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Insulation | Polyamide (PA), Nylon |
| Manufacturer Standard Lead Time | 11 Weeks | Length - Termination | 0.404" (10.26mm) |
| Length - Ring Center to Termination | 0.203" (5.16mm) | Length - Overall | 0.727" (18.47mm) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Diameter | 0.105" ~ 0.140" (2.67mm ~ 3.56mm) |
| Insulation | Insulated | Features | Serrated Termination |
| Detailed Description | Red 2 Stud Spade Terminal Connector Crimp 16-22 AWG | Contact Material | Copper |
| Contact Finish | Tin | Color | Red |
