1776275-6
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1776275-6 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1776275-6 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1776275-6 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | TERM BLOCK 6POS SIDE ENT 3.5MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.757 | $0.574 | $0.532 | $0.479 | $0.467 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.409 | $0.374 | $0.339 | $0.298 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1776275-6 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | TERM BLOCK 6POS SIDE ENT 3.5MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 64982 pcs | Data sheet | Terminal Blocks, Eurostyle1776275 Drawing |
| Category | Connectors, Interconnects | Wire Termination | Screw - Leaf Spring, Wire Guard |
| Wire Gauge | 18-26 AWG | Voltage | 250V |
| Torque - Screw | 0.28 Nm (2.5 Lb-In) | Series | Buchanan |
| Screw Thread | M2.6 | Screw Material - Plating | Steel, Galvanized - Chromate Plated |
| Positions Per Level | 6 | Pitch | 0.138" (3.50mm) |
| Packaging | Bulk | Other Names | 17762756 A98040 |
| Operating Temperature | -55°C ~ 105°C | Number of Levels | 1 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Orientation | Horizontal with Board | Manufacturer Standard Lead Time | 14 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Housing Material | Polyamide (PA66), Nylon 6/6 |
| Features | Interlocking (Side) | Detailed Description | 6 Position Wire to Board Terminal Block Horizontal with Board 0.138" (3.50mm) Through Hole |
| Current | 7A | Contact Material - Plating | Brass - Copper Tin Plated |
| Color | Blue | Clamp Material - Plating | Steel, Stainless |
