Home > Products > Connectors, Interconnects > Rectangular Connectors - Headers, Male Pins > 1-770859-1

1-770859-1

1-770859-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1-770859-1 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number 1-770859-1
Manufacturer Agastat Relays / TE Connectivity
Description CONN HEADER 15POS VERT MINI-UMNL
Lead Free Status / RoHS Status Lead free / RoHS Compliant
In Stock 18267 pcs
Reference Price
(In US Dollars)		1 pcs10 pcs100 pcs500 pcs1000 pcs
$3.437$3.286$2.764$2.315$2.047

Submit a Request For Quotation on quantities greater than those displayed.

Target Price:(USD)
Quantity:
Total:
$3.437

Product parameter

Part Number 1-770859-1 Manufacturer Agastat Relays / TE Connectivity
Description CONN HEADER 15POS VERT MINI-UMNL Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 18267 pcs Data sheet 770859 Drawing
Category Connectors, Interconnects Voltage Rating 600VAC
Termination Solder Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall Series Mini-Universal MATE-N-LOK
Row Spacing - Mating 0.163" (4.14mm) Pitch - Mating 0.163" (4.14mm)
Packaging Bulk Overall Contact Length -
Other Names 1-770859-1-ND
17708591
A112751		 Operating Temperature -20°C ~ 105°C
Number of Rows 3 Number of Positions Loaded All
Number of Positions 15 Mounting Type Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited) Material Flammability Rating UL94 V-0
Mated Stacking Heights - Manufacturer Standard Lead Time 12 Weeks
Lead Free Status / RoHS Status Lead free / RoHS Compliant Insulation Material Polyamide (PA), Nylon
Insulation Height 0.531" (13.50mm) Insulation Color White
Ingress Protection - Features Board Lock
Fastening Type Locking Ramp Detailed Description Connector Header Through Hole 15 position 0.163" (4.14mm)
Current Rating Varies by Wire Gauge Contact Type Male Pin
Contact Shape Circular Contact Material Brass
Contact Length - Post 0.175" (4.45mm) Contact Length - Mating -
Contact Finish Thickness - Post 150.0µin (3.81µm) Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Finish - Post Tin Contact Finish - Mating Gold
Connector Type Header Applications General Purpose
