1-770849-2
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1-770849-2 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1-770849-2 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1-770849-2 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN RECEPT 12POS W/RAMP SL156 |
| Lead Free Status / RoHS Status | Not applicable / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.214 | $0.199 | $0.179 | $0.16 | $0.153 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.14 | $0.133 | $0.11 | $0.10 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1-770849-2 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN RECEPT 12POS W/RAMP SL156 | Lead Free Status / RoHS Status | Not applicable / RoHS Compliant |
| Quantity Available | 205923 pcs | Data sheet | 770849 Drawing |
| Category | Connectors, Interconnects | Series | SL-156 |
| Row Spacing | - | Pitch | 0.156" (3.96mm) |
| Packaging | Bulk | Other Names | 1-770849-2-ND A24121 |
| Number of Rows | 1 | Number of Positions | 12 |
| Note | Contacts Not Included | Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 13 Weeks |
| Lead Free Status / RoHS Status | Not applicable / RoHS Compliant | Features | Polarizing Key |
| Fastening Type | Locking Ramp | Detailed Description | 12 Position Rectangular Housing Connector Receptacle Natural 0.156" (3.96mm) |
| Contact Type | Female Socket | Contact Termination | Crimp |
| Connector Type | Receptacle | Color | Natural |
