1-2199299-5
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1-2199299-5 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1-2199299-5 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1-2199299-5 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | 40P,DIP SKT,600 CL,LDR,PB FREE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.313 | $0.275 | $0.259 | $0.248 | $0.238 | |
| 250 pcs | 500 pcs | 1200 pcs | 3600 pcs | ||
| $0.216 | $0.194 | $0.173 | $0.157 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1-2199299-5 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | 40P,DIP SKT,600 CL,LDR,PB FREE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 139291 pcs | Data sheet | 2199299 Drawing |
| Category | Connectors, Interconnects | Type | DIP, 0.6" (15.24mm) Row Spacing |
| Termination Post Length | 0.118" (3.00mm) | Termination | Solder |
| Series | Diplomate DL | Pitch - Post | 0.100" (2.54mm) |
| Pitch - Mating | 0.100" (2.54mm) | Packaging | Bulk |
| Other Names | A120355 | Operating Temperature | -40°C ~ 105°C |
| Number of Positions or Pins (Grid) | 40 (2 x 20) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 19 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled | Features | Open Frame |
| Current Rating | 1A | Contact Resistance | 20 mOhm |
| Contact Material - Post | Nickel | Contact Material - Mating | Phosphor Bronze |
| Contact Finish Thickness - Post | 60.0µin (1.52µm) | Contact Finish Thickness - Mating | 60.0µin (1.52µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Tin |
