1052630002
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1052630002 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1052630002 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1052630002 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | RF ANT 850MHZ/900MHZ FLAT 150MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $2.385 | $2.131 | $1.917 | $1.747 | ||
| 416 pcs | 832 pcs | 1248 pcs | 2912 pcs | ||
| $1.577 | $1.278 | $1.193 | $1.133 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1052630002 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | RF ANT 850MHZ/900MHZ FLAT 150MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 27784 pcs | Data sheet | 105263000x Drawing105263-002 Prod Spec105263 Series |
| Category | RF/IF and RFID | VSWR | - |
| Termination | Cable (150mm) - U.FL | Series | 105263 |
| Return Loss | -6.8dB, -7.5dB, -7.7dB, -8.5dB, -10.5dB, -11dB | Power - Max | 2W |
| Packaging | Tray | Other Names | 105263-0002 WM9670 |
| Number of Bands | 6 | Mounting Type | Adhesive |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Height (Max) | 0.004" (0.10mm) | Gain | 1.5dBi, 1.7dBi, 1.8dBi, 2.1dBi, 2.2dBi, 3dBi |
| Frequency Range | 824MHz ~ 960MHz, 1.71GHz ~ 2.17GHz, 2.5GHz ~ 2.69GHz | Frequency Group | Wide Band |
| Frequency (Center/Band) | 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2GHz, 2.6GHz | Features | - |
| Detailed Description | 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2GHz, 2.6GHz GSM, LTE, UMTS Flat Patch RF Antenna 824MHz ~ 960MHz, 1.71GHz ~ 2.17GHz, 2.5GHz ~ 2.69GHz 1.5dBi, 1.7dBi, 1.8dBi, 2.1dBi, 2.2dBi, 3dBi Cable (150mm) - U.FL Adhesive | Applications | GSM, LTE, UMTS |
| Antenna Type | Flat Patch |
