1052630001
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1052630001 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1052630001 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1052630001 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | RF ANT 850/900MHZ FLAT 100MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $1.486 | $1.328 | $1.195 | $1.089 | ||
| 416 pcs | 832 pcs | 1248 pcs | 2912 pcs | ||
| $0.982 | $0.797 | $0.743 | $0.706 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1052630001 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | RF ANT 850/900MHZ FLAT 100MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 49026 pcs | Data sheet | 105263 Series105263-0001 Prod Spec105263000x Drawing |
| Category | RF/IF and RFID | VSWR | - |
| Termination | Cable (100mm) - U.FL | Series | 105263 |
| Return Loss | -6.8dB, -7dB, -7.5dB, -10dB, -10.5dB | Power - Max | 2W |
| Packaging | Tray | Other Names | 105263-0001 WM9405 |
| Number of Bands | 6 | Mounting Type | Adhesive |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Height (Max) | 0.004" (0.10mm) | Gain | 2dBi, 2.2dBi, 2.3dBi, 3.1dBi |
| Frequency Range | 824MHz ~ 894MHz, 880MHz ~ 960MHz, 1.71GHz ~ 1.88GHz, 1.85GHz ~ 1.99GHz, 1.92GHz ~ 2.17GHz, 2.5GHz ~ 2.69GHz | Frequency Group | Wide Band |
| Frequency (Center/Band) | 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2GHz, 2.6GHz | Features | - |
| Detailed Description | 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2GHz, 2.6GHz GSM, LTE, UMTS Flat Patch RF Antenna 824MHz ~ 894MHz, 880MHz ~ 960MHz, 1.71GHz ~ 1.88GHz, 1.85GHz ~ 1.99GHz, 1.92GHz ~ 2.17GHz, 2.5GHz ~ 2.69GHz 2dBi, 2.2dBi, 2.3dBi, 3.1dBi Cable (100mm) - U.FL Adhesive | Applications | GSM, LTE, UMTS |
| Antenna Type | Flat Patch |
