580200B00000G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 580200B00000G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 580200B00000G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 580200B00000G |
|---|---|
| Manufacturer | Aavid Thermalloy |
| Description | HEATSINK 14-16 DIP BLK ANODIZED |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.26 | $0.247 | $0.234 | $0.228 | $0.225 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.21 | $0.197 | $0.179 | $0.173 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 580200B00000G | Manufacturer | Aavid Thermalloy |
|---|---|---|---|
| Description | HEATSINK 14-16 DIP BLK ANODIZED | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 136345 pcs | Data sheet | Standard Heatsinks Catalog5x0200x00000G |
| Category | Fans, Thermal Management | Width | 0.600" (15.24mm) |
| Type | Top Mount | Thermal Resistance @ Natural | 20.00°C/W |
| Thermal Resistance @ Forced Air Flow | 12.00°C/W @ 200 LFM | Shape | Rectangular, Fins |
| Series | - | Power Dissipation @ Temperature Rise | 1.0W @ 20°C |
| Package Cooled | 14-DIP and 16-DIP | Other Names | 002668 580200B00000 HS179 |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 7 Weeks |
| Length | 0.890" (22.61mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.410" (10.42mm) | Diameter | - |
| Detailed Description | Heat Sink 14-DIP and 16-DIP Aluminum 1.0W @ 20°C Top Mount | Attachment Method | Press Fit, Slide On |
