342948
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 342948 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 342948 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 342948 |
|---|---|
| Manufacturer | Aavid Thermalloy |
| Description | COPPER HEATSINK 70X69X14MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $14.485 | $13.631 | $12.779 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $11.927 | $11.501 | $10.862 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 342948 | Manufacturer | Aavid Thermalloy |
|---|---|---|---|
| Description | COPPER HEATSINK 70X69X14MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3142 pcs | Data sheet | 342940-50 Datasheet |
| Category | Fans, Thermal Management | Width | 2.756" (70.00mm) |
| Type | Top Mount | Thermal Resistance @ Natural | 5.60°C/W |
| Thermal Resistance @ Forced Air Flow | 1.40°C/W @ 200 LFM | Shape | Square, Fins |
| Series | - | Power Dissipation @ Temperature Rise | - |
| Package Cooled | BGA | Other Names | 342948-ND HS484 |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material Finish | AavSHIELD 3C |
| Material | Copper | Manufacturer Standard Lead Time | 8 Weeks |
| Length | 2.717" (69.00mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.551" (14.00mm) | Diameter | - |
| Detailed Description | Heat Sink BGA Copper Top Mount | Attachment Method | Push Pin |
