V5220W
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy V5220W with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy V5220W with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | V5220W |
|---|---|
| Manufacturer | ASSMANN WSW Components |
| Description | HEATSINK ANOD ALUM W/PIN TO-220 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 56 pcs | 112 pcs |
|---|---|---|---|---|---|
| $0.245 | $0.233 | $0.221 | $0.215 | $0.212 | |
| 280 pcs | 504 pcs | 1008 pcs | 5040 pcs | ||
| $0.198 | $0.186 | $0.169 | $0.163 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | V5220W | Manufacturer | ASSMANN WSW Components |
|---|---|---|---|
| Description | HEATSINK ANOD ALUM W/PIN TO-220 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 129235 pcs | Data sheet | V5220x Drawing |
| Category | Fans, Thermal Management | Width | 1.260" (32.00mm) |
| Type | Board Level, Vertical | Thermal Resistance @ Natural | 10.00°C/W |
| Thermal Resistance @ Forced Air Flow | - | Shape | Rectangular, Fins |
| Series | - | Power Dissipation @ Temperature Rise | - |
| Package Cooled | TO-220 | Other Names | AE10798 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 20 Weeks |
| Length | 0.984" (25.00mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.787" (19.99mm) | Diameter | - |
| Detailed Description | Heat Sink TO-220 Aluminum Board Level, Vertical | Attachment Method | Bolt On |
