TIP142T
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TIP142T with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TIP142T with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TIP142T |
|---|---|
| Manufacturer | AMI Semiconductor / ON Semiconductor |
| Description | TRANS NPN DARL 100V 10A TO220-3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | TIP142T | Manufacturer | AMI Semiconductor / ON Semiconductor |
|---|---|---|---|
| Description | TRANS NPN DARL 100V 10A TO220-3 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6014 pcs | Data sheet | TIP140-42TO220B03 Pkg Drawing |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 100V |
| Vce Saturation (Max) @ Ib, Ic | 3V @ 40mA, 10A | Transistor Type | NPN - Darlington |
| Supplier Device Package | TO-220-3 | Series | - |
| Power - Max | 80W | Packaging | Bulk |
| Package / Case | TO-220-3 | Other Names | TIP142TFS |
| Operating Temperature | 150°C (TJ) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Frequency - Transition | - | Detailed Description | Bipolar (BJT) Transistor NPN - Darlington 100V 10A 80W Through Hole TO-220-3 |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 1000 @ 5A, 4V | Current - Collector Cutoff (Max) | 2mA |
| Current - Collector (Ic) (Max) | 10A | Base Part Number | TIP142 |
