HGTG20N60A4D
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HGTG20N60A4D with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HGTG20N60A4D with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HGTG20N60A4D |
|---|---|
| Manufacturer | AMI Semiconductor / ON Semiconductor |
| Description | IGBT 600V 70A 290W TO247 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 450 pcs | 900 pcs | 1350 pcs |
|---|---|---|---|---|---|
| $1.91 | $1.717 | $1.335 | $1.197 | $1.01 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | HGTG20N60A4D | Manufacturer | AMI Semiconductor / ON Semiconductor |
|---|---|---|---|
| Description | IGBT 600V 70A 290W TO247 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 37217 pcs | Data sheet | HGTG20N60A4D |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 600V |
| Vce(on) (Max) @ Vge, Ic | 2.7V @ 15V, 20A | Test Condition | 390V, 20A, 3 Ohm, 15V |
| Td (on/off) @ 25°C | 15ns/73ns | Switching Energy | 105µJ (on), 150µJ (off) |
| Supplier Device Package | TO-247 | Series | - |
| Reverse Recovery Time (trr) | 35ns | Power - Max | 290W |
| Packaging | Tube | Package / Case | TO-247-3 |
| Other Names | HGTG20N60A4D-ND HGTG20N60A4D_NL HGTG20N60A4D_NL-ND HGTG20N60A4DFS |
Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Type | Standard |
| IGBT Type | - | Gate Charge | 142nC |
| Detailed Description | IGBT 600V 70A 290W Through Hole TO-247 | Current - Collector Pulsed (Icm) | 280A |
| Current - Collector (Ic) (Max) | 70A | Base Part Number | HGTG20N60 |
