Home > Products > Isolators > Optoisolators - Transistor, Photovoltaic Output > H11G1M

H11G1M

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy H11G1M with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	H11G1M
Manufacturer	AMI Semiconductor / ON Semiconductor
Description	OPTOISO 4.17KV DARL W/BASE 6DIP
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 166947 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	100 pcs	500 pcs	1000 pcs
Reference Price (In US Dollars)	$0.385	$0.30	$0.214	$0.163	$0.129

Product parameter
Data sheet

Product parameter

Part Number	H11G1M	Manufacturer	AMI Semiconductor / ON Semiconductor
Description	OPTOISO 4.17KV DARL W/BASE 6DIP	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	166947 pcs	Data sheet	H11G1M-3M
Category	Isolators	Voltage - Output (Max)	100V
Voltage - Isolation	4170Vrms	Voltage - Forward (Vf) (Typ)	1.3V
Vce Saturation (Max)	1V	Turn On / Turn Off Time (Typ)	-
Supplier Device Package	6-DIP	Series	-
Rise / Fall Time (Typ)	-	Packaging	Tube
Package / Case	6-DIP (0.300", 7.62mm)	Output Type	Darlington with Base
Operating Temperature	-40°C ~ 100°C	Number of Channels	1
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	9 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Input Type	DC	Detailed Description	Optoisolator Darlington with Base Output 4170Vrms 1 Channel 6-DIP
Current Transfer Ratio (Min)	1000% @ 10mA	Current Transfer Ratio (Max)	-
Current - Output / Channel	-	Current - DC Forward (If) (Max)	60mA
