FDPC5030SG
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FDPC5030SG with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy FDPC5030SG with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | FDPC5030SG |
|---|---|
| Manufacturer | AMI Semiconductor / ON Semiconductor |
| Description | MOSFET 2N-CH 30V PWRCLIP56 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | ||||
|---|---|---|---|---|---|
| $0.233 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | FDPC5030SG | Manufacturer | AMI Semiconductor / ON Semiconductor |
|---|---|---|---|
| Description | MOSFET 2N-CH 30V PWRCLIP56 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 100795 pcs | Data sheet | FDPC5030SG |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 3V @ 250µA |
| Supplier Device Package | Power Clip 56 | Series | PowerTrench® |
| Rds On (Max) @ Id, Vgs | 5 mOhm @ 17A, 10V | Power - Max | 1W, 1.1W |
| Packaging | Tape & Reel (TR) | Package / Case | 8-PowerWDFN |
| Other Names | FDPC5030SGTR | Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 26 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 1715pF @ 15V | Gate Charge (Qg) (Max) @ Vgs | 24nC @ 10V |
| FET Type | 2 N-Channel (Dual) Asymmetrical | FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 30V | Detailed Description | Mosfet Array 2 N-Channel (Dual) Asymmetrical 30V 17A, 25A 1W, 1.1W Surface Mount Power Clip 56 |
| Current - Continuous Drain (Id) @ 25°C | 17A, 25A |
