ADRF5024BCCZN
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ADRF5024BCCZN with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ADRF5024BCCZN with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ADRF5024BCCZN |
|---|---|
| Manufacturer | ADI (Analog Devices, Inc.) |
| Description | 40GHZ, LOW LOSS, REFLECTIVE, FAS |
| Lead Free Status / RoHS Status | RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | |||
|---|---|---|---|---|---|
| $40.898 | $38.562 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ADRF5024BCCZN | Manufacturer | ADI (Analog Devices, Inc.) |
|---|---|---|---|
| Description | 40GHZ, LOW LOSS, REFLECTIVE, FAS | Lead Free Status / RoHS Status | RoHS Compliant |
| Quantity Available | 797 pcs | Data sheet | ADRF5024 |
| Category | RF/IF and RFID | Voltage - Supply | 3.15 V ~ 3.45 V |
| Topology | Reflective | Test Frequency | 44GHz |
| Supplier Device Package | 12-LGA (2.25x2.25) | Series | - |
| RoHS Status | RoHS Compliant | RF Type | General Purpose |
| Packaging | Strip | Package / Case | 12-VFLGA |
| P1dB | 27.5dBm | Operating Temperature | -40°C ~ 105°C |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Isolation | 35dB |
| Insertion Loss | 1.7dB | Impedance | 50 Ohm |
| IIP3 | 50dBm | Frequency Range | 100MHz ~ 44GHz |
| Features | - | Detailed Description | RF Switch IC General Purpose SPDT 50 Ohm 12-LGA (2.25x2.25) |
| Circuit | SPDT |
