ADG859YRYZ-REEL7
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ADG859YRYZ-REEL7 with confidence from Components-World.HK, 1 Year Warranty
Dowload ADG859YRYZ-REEL7 Details in PDFSee Product Specifications for product details.
Buy ADG859YRYZ-REEL7 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ADG859YRYZ-REEL7 |
|---|---|
| Manufacturer | ADI (Analog Devices, Inc.) |
| Description | IC SWITCH SPDT SOT66 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ADG859YRYZ-REEL7 | Manufacturer | ADI (Analog Devices, Inc.) |
|---|---|---|---|
| Description | IC SWITCH SPDT SOT66 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4519 pcs | Data sheet | ADG859 |
| Category | Integrated Circuits (ICs) | Voltage - Supply, Single (V+) | 1.8 V ~ 5.5 V |
| Voltage - Supply, Dual (V±) | - | Switch Time (Ton, Toff) (Max) | 10ns, 6ns |
| Switch Circuit | SPDT | Supplier Device Package | SOT-66 |
| Series | - | Packaging | Cut Tape (CT) |
| Package / Case | SOT-66 | Other Names | ADG859YRYZ-REEL7CT |
| Operating Temperature | -40°C ~ 125°C (TA) | On-State Resistance (Max) | 2.1 Ohm |
| Number of Circuits | 1 | Multiplexer/Demultiplexer Circuit | 2:1 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Detailed Description | 1 Circuit IC Switch 2:1 2.1 Ohm SOT-66 | Current - Leakage (IS(off)) (Max) | 20pA (Typ) |
| Crosstalk | -78dB @ 100kHz | Charge Injection | 13pC |
| Channel-to-Channel Matching (ΔRon) | 10 mOhm | Channel Capacitance (CS(off), CD(off)) | 18pF |
| Base Part Number | ADG859 | -3db Bandwidth | 125MHz |
