Home > Products > Connectors, Interconnects > Backplane Connectors - Hard Metric, Standard > CP2-HB095-GA1-KR

CP2-HB095-GA1-KR

CP2-HB095-GA1-KR

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CP2-HB095-GA1-KR with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	CP2-HB095-GA1-KR
Manufacturer	3M
Description	HEADER PRESS-FIT TYPE B 95POS
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 17980 pcs
Reference Price (In US Dollars)	1344 pcs
Reference Price (In US Dollars)	$1.678

Product parameter
Data sheet

Product parameter

Part Number	CP2-HB095-GA1-KR	Manufacturer	3M
Description	HEADER PRESS-FIT TYPE B 95POS	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	17980 pcs	Data sheet	CP2 Series
Category	Connectors, Interconnects	Voltage Rating	-
Termination	Press-Fit	Series	MetPak™ CP2
Pitch	0.079" (2.00mm)	Packaging	Bulk
Other Names	00051119905748 05111990574 3M15503 5111990574 51119905748 80001203183 CP2-HB095-GA1-KR-ND	Operating Temperature	-40°C ~ 85°C
Number of Rows	5 + 2	Number of Positions Loaded	All
Number of Positions	133 (95 + 38 Ground)	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	9 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Features	-
Detailed Description	133 (95 + 38 Ground) Position Header, Male Pins Connector 0.079" (2.00mm) Through Hole	Contact Finish Thickness	30.0µin (0.76µm)
Contact Finish	Gold	Connector Usage	CompactPCI Hot Swap
Connector Type	Header, Male Pins	Connector Style	B 19
