7816-0000PR
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 7816-0000PR with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 7816-0000PR with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 7816-0000PR |
|---|---|
| Manufacturer | 3M |
| Description | CONN 16POS .1X.1 IDC RIBBON PCB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $1.162 | $1.115 | $1.022 | $0.976 | $0.929 | |
| 300 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.813 | $0.79 | $0.674 | $0.627 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 7816-0000PR | Manufacturer | 3M |
|---|---|---|---|
| Description | CONN 16POS .1X.1 IDC RIBBON PCB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 50857 pcs | Data sheet | 78xx Series |
| Category | Connectors, Interconnects | Wire Gauge | 26 AWG, Stranded; 28 AWG, Solid or Stranded; 30 AWG, Solid |
| Series | 78XX | Row Spacing | 0.100" (2.54mm) |
| Packaging | Tray | Other Names | 04547452253906 3M11959 7000090298 7816-0000PR-ND 78160000PR JE150319026 |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 16 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 8 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Feed Through |
| Detailed Description | 16 Position Ribbon Cable, DIP Header Connector Gray IDC 26 AWG, Stranded; 28 AWG, Solid or Stranded; 30 AWG, Solid Through Hole | Contact Finish Thickness | Flash |
| Contact Finish | Gold | Connector Type | Ribbon Cable, DIP Header |
| Color | Gray | Cable Termination | IDC |
| Cable Pitch | 0.050" (1.27mm) | Board-Side Pitch | 0.100" (2.54mm) |
