Home > Products > Integrated Circuits (ICs) > Embedded - Microcontrollers - Application Specific > Z86E4704PSG

Z86E4704PSG

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy Z86E4704PSG with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	Z86E4704PSG
Manufacturer	Zilog
Description	IC DTC 16K OTP 64-DIP
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4751 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	Z86E4704PSG	Manufacturer	Zilog
Description	IC DTC 16K OTP 64-DIP	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4751 pcs	Data sheet	Z86C47, Z86E47
Category	Integrated Circuits (ICs)	Voltage - Supply	4.5 V ~ 5.5 V
Supplier Device Package	64-DIP	Series	-
RAM Size	236 x 8	Program Memory Type	OTP (16 kB)
Packaging	Tube	Package / Case	64-DIP (0.750", 19.05mm)
Operating Temperature	0°C ~ 70°C	Number of I/O	35
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Interface	-
Core Processor	Z8	Controller Series	Digital Television Controller (DTC)
Base Part Number	Z86E47	Applications	TV Controller
