JTF1224S3V3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy JTF1224S3V3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy JTF1224S3V3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | JTF1224S3V3 |
|---|---|
| Manufacturer | XP Power |
| Description | DC DC CONVERTER 3.3V 12W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | 100 pcs |
|---|---|---|---|---|---|
| $11.107 | $10.774 | $10.44 | $9.996 | $9.388 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | JTF1224S3V3 | Manufacturer | XP Power |
|---|---|---|---|
| Description | DC DC CONVERTER 3.3V 12W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3375 pcs | Data sheet | JTF Series, 8-15 W Datasheet |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | - | Voltage - Output 1 | 3.3V |
| Voltage - Isolation | 1.6kV | Voltage - Input (Min) | 9V |
| Voltage - Input (Max) | 36V | Type | Isolated Module |
| Size / Dimension | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) | Series | JTF |
| Power (Watts) | 12W | Packaging | Tube |
| Package / Case | 24-DIP Module, 8 Leads | Other Names | 1470-2101-5 |
| Operating Temperature | -40°C ~ 105°C | Number of Outputs | 1 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 11 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Remote On/Off, OCP, OVP, SCP | Efficiency | 87% |
| Detailed Description | Isolated Module DC DC Converter 1 Output 3.3V 3.5A 9V - 36V Input | Current - Output (Max) | 3.5A |
| Control Features | Enable, Active High | Applications | ITE (Commercial) |
