ECM100UD22
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ECM100UD22 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ECM100UD22 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ECM100UD22 |
|---|---|
| Manufacturer | XP Power |
| Description | AC/DC CONVERTER 5V 15V 100W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $36.08 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ECM100UD22 | Manufacturer | XP Power |
|---|---|---|---|
| Description | AC/DC CONVERTER 5V 15V 100W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1078 pcs | Data sheet | ECM Series, 40-100 W - Long DatasheetECM Series, 40-100 W - Short Datasheet |
| Category | Power Supplies - External/Internal (Off-Board) | Voltage - Output 4 | - |
| Voltage - Output 3 | - | Voltage - Output 2 | 15V |
| Voltage - Output 1 | 5V | Voltage - Isolation | 4kV |
| Voltage - Input | 90 ~ 264 VAC | Type | Open Frame |
| Size / Dimension | 4.50" L x 2.50" W x 1.20" H (114.3mm x 63.5mm x 30.5mm) | Series | ECM |
| Power (Watts) | 80W (100W Forced Air) | Operating Temperature | 0°C ~ 70°C (With Derating) |
| Number of Outputs | 2 | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Minimum Load Required | Yes |
| Manufacturer Standard Lead Time | 18 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Adjustable Output, DC Input Capable, Universal Input | Efficiency | 80% |
| Detailed Description | Open Frame AC DC Converter 2 Output 5V 15V 12A, 3A 90 ~ 264 VAC Input | Current - Output (Max) | 12A, 3A |
| Approvals | CB, CE | Applications | ITE (Commercial), Medical |
