CB101
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CB101 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CB101 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CB101 |
|---|---|
| Manufacturer | XP Power |
| Description | DC DC CONVERTER 10000V 1W |
| Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | ||
|---|---|---|---|---|---|
| $158.744 | $156.362 | $153.981 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | CB101 | Manufacturer | XP Power |
|---|---|---|---|
| Description | DC DC CONVERTER 10000V 1W | Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant |
| Quantity Available | 224 pcs | Data sheet | CB Series Datasheet |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | - | Voltage - Output 1 | 10000V |
| Voltage - Input (Min) | 11.5V | Voltage - Input (Max) | 15.5V |
| Type | High Voltage - Non-Isolated Module | Size / Dimension | 3.00" L x 1.25" W x 0.60" H (82.6mm x 31.8mm x 15.2mm) |
| Series | XP EMCO - CB | Power (Watts) | 1W |
| Packaging | Box | Package / Case | 8-DIP Module |
| Other Names | 1470-3277 | Operating Temperature | -10°C ~ 60°C |
| Number of Outputs | 1 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant | Features | OTP, OVP |
| Efficiency | - | Detailed Description | High Voltage - Non-Isolated Module DC DC Converter 1 Output 10000V 100µA 11.5V - 15.5V Input |
| Current - Output (Max) | 100µA | Applications | ITE (Commercial) |
