AG05P-12
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AG05P-12 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy AG05P-12 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AG05P-12 |
|---|---|
| Manufacturer | XP Power |
| Description | DC DC CONVERTER 500V 1W |
| Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | 100 pcs |
|---|---|---|---|---|---|
| $28.249 | $27.825 | $27.401 | $26.554 | $25.706 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | AG05P-12 | Manufacturer | XP Power |
|---|---|---|---|
| Description | DC DC CONVERTER 500V 1W | Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant |
| Quantity Available | 1250 pcs | Data sheet | AG,AGH Series Datasheet |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | - | Voltage - Output 1 | 500V |
| Voltage - Isolation | 500V | Voltage - Input (Min) | 0.7V |
| Voltage - Input (Max) | 12V | Type | High Voltage - Isolated Module |
| Size / Dimension | 0.92" L x 0.45" W x 0.25" H (23.4mm x 11.4mm x 6.4mm) | Series | XP EMCO - AG |
| Power (Watts) | 1W | Packaging | Box |
| Package / Case | 5-SMD Module | Other Names | 1470-3206 |
| Operating Temperature | -25°C ~ 75°C | Number of Outputs | 1 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 27 Weeks | Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant |
| Features | SCP | Efficiency | - |
| Detailed Description | High Voltage - Isolated Module DC DC Converter 1 Output 500V 2mA 0.7V - 12V Input | Current - Output (Max) | 2mA |
| Applications | ITE (Commercial) |
