784771100
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 784771100 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 784771100 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 784771100 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | FIXED IND 10UH 5A 26.5 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 500 pcs | ||||
|---|---|---|---|---|---|
| $0.564 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 784771100 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | FIXED IND 10UH 5A 26.5 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 69753 pcs | Data sheet | 784771100 DrawingQ+ Products Flyer |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | 1260 |
| Size / Dimension | 0.472" L x 0.472" W (12.00mm x 12.00mm) | Shielding | Shielded |
| Series | WE-PDA | Ratings | AEC-Q200 |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Other Names | 732-6772-2 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Nickel Zinc Ferrite (NiZn) |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 100kHz | Inductance | 10µH |
| Height - Seated (Max) | 0.248" (6.30mm) | Frequency - Self Resonant | 22.3MHz |
| Detailed Description | 10µH Shielded Wirewound Inductor 5A 26.5 mOhm Max Nonstandard | DC Resistance (DCR) | 26.5 mOhm Max |
| Current Rating | 5A | Current - Saturation | 5.25A |
