7447745220
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 7447745220 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 7447745220 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 7447745220 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | FIXED IND 22UH 1.05A 330 MOHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 2000 pcs | ||||
|---|---|---|---|---|---|
| $0.398 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 7447745220 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | FIXED IND 22UH 1.05A 330 MOHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 93495 pcs | Data sheet | 7447745220 |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.228" L x 0.205" W (5.80mm x 5.20mm) | Shielding | Unshielded |
| Series | WE-PD2 | Ratings | - |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Other Names | 732-4145-2 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 100kHz | Inductance | 22µH |
| Height - Seated (Max) | 0.091" (2.30mm) | Frequency - Self Resonant | 24MHz |
| Detailed Description | 22µH Unshielded Wirewound Inductor 1.05A 330 mOhm Max Nonstandard | DC Resistance (DCR) | 330 mOhm Max |
| Current Rating | 1.05A | Current - Saturation | 1.2A |
