744770112
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 744770112 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 744770112 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 744770112 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | FIXED IND 12UH 5.9A 24 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 500 pcs | 1000 pcs | |||
|---|---|---|---|---|---|
| $0.505 | $0.454 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 744770112 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | FIXED IND 12UH 5.9A 24 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 83265 pcs | Data sheet | 744770112 Drawing |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.472" L x 0.472" W (12.00mm x 12.00mm) | Shielding | Shielded |
| Series | WE-PD | Ratings | - |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Other Names | 732-1224-2 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 1kHz | Inductance | 12µH |
| Height - Seated (Max) | 0.315" (8.00mm) | Frequency - Self Resonant | 16MHz |
| Detailed Description | 12µH Shielded Wirewound Inductor 5.9A 24 mOhm Max Nonstandard | DC Resistance (DCR) | 24 mOhm Max |
| Current Rating | 5.9A | Current - Saturation | 6.3A |
