74456122
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 74456122 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 74456122 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 74456122 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | FIXED IND 22UH 2.6A 95 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | 250 pcs |
|---|---|---|---|---|---|
| $0.683 | $0.651 | $0.607 | $0.564 | $0.52 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 74456122 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | FIXED IND 22UH 2.6A 95 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 74242 pcs | Data sheet | 74456122 |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.500" L x 0.394" W (12.70mm x 10.00mm) | Shielding | Unshielded |
| Series | WE-PD4 | Ratings | - |
| Q @ Freq | - | Packaging | Cut Tape (CT) |
| Package / Case | Nonstandard | Other Names | 732-1352-1 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 100kHz | Inductance | 22µH |
| Height - Seated (Max) | 0.209" (5.30mm) | Frequency - Self Resonant | 14MHz |
| Detailed Description | 22µH Unshielded Wirewound Inductor 2.6A 95 mOhm Max Nonstandard | DC Resistance (DCR) | 95 mOhm Max |
| Current Rating | 2.6A | Current - Saturation | 3.1A |
