Home > Products > Relays > Power Relays, Over 2 Amps > 8536681001

8536681001

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 8536681001 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	8536681001
Manufacturer	Weidmuller
Description	RELAY GEN PURPOSE DPDT 10A 24V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4742 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$7.809

Product parameter
Data sheet

Product parameter

Part Number	8536681001	Manufacturer	Weidmuller
Description	RELAY GEN PURPOSE DPDT 10A 24V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4742 pcs	Data sheet	8536681001
Category	Relays	Turn On Voltage (Max)	18 VAC
Turn Off Voltage (Min)	3.6 VAC	Termination Style	Spring Terminal
Switching Voltage	250VAC - Max	Series	PRZ
Relay Type	General Purpose with Socket	Packaging	Bulk
Operating Temperature	-40°C ~ 50°C	Mounting Type	DIN Rail
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Features	LED Indicator	Detailed Description	General Purpose with Socket Relay DPDT (2 Form C) 24VAC Coil DIN Rail
Contact Rating (Current)	10A	Contact Material	-
Contact Form	DPDT (2 Form C)	Coil Voltage	24VAC
Coil Type	Non Latching	Coil Resistance	350 Ohms
Coil Power	0.8 VA	Coil Current	30.5mA
