6760005558
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 6760005558 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 6760005558 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 6760005558 |
|---|---|
| Manufacturer | Weidmuller |
| Description | TERM BLOCK PLUG 9POS STR 5.08MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $3.838 | $3.287 | $3.137 | $2.82 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.67 | $2.42 | $2.253 | $2.127 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 6760005558 | Manufacturer | Weidmuller |
|---|---|---|---|
| Description | TERM BLOCK PLUG 9POS STR 5.08MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 14631 pcs | Data sheet | 6760005558 Drawing |
| Category | Connectors, Interconnects | Wire Strip Length | 10mm |
| Wire Gauge or Range - mm² | - | Wire Gauge or Range - AWG | - |
| Type | Plug, Female Sockets | Torque - Screw | - |
| Termination Style | Screwless - Leg Spring, Push-In Spring | Series | Omnimate BL |
| Screw Size | - | Positions Per Level | 9 |
| Plug Wire Entry | 180° | Pitch | 0.200" (5.08mm) |
| Packaging | Bulk | Other Names | 10144501-9 10144501-9-ND 281-3186 6760005558-ND Q7190231 |
| Operating Temperature | -50°C ~ 100°C | Number of Positions | 9 |
| Number of Levels | 1 | Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Height | 0.564" (14.33mm) | Ingress Protection | IP20 |
| Housing Material | Polybutylene Terephthalate (PBT) | Header Orientation | - |
| Features | Ejector Latches, Positions Stamped, Retention Latches (Non-Wire Side) | Detailed Description | 9 Position Terminal Block Plug, Female Sockets 0.200" (5.08mm) 180° Free Hanging (In-Line) |
| Current - IEC | - | Contact Tail Length | - |
| Contact Mating Finish | Tin | Contact Material | Copper Alloy |
| Color | Orange |
