1630730000
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1630730000 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1630730000 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1630730000 |
|---|---|
| Manufacturer | Weidmuller |
| Description | TERM BLOCK HDR 4POS VERT 5.08MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $1.025 | $0.775 | $0.719 | $0.646 | $0.631 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.552 | $0.504 | $0.457 | $0.402 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1630730000 | Manufacturer | Weidmuller |
|---|---|---|---|
| Description | TERM BLOCK HDR 4POS VERT 5.08MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 96908 pcs | Data sheet | 1630730000 |
| Category | Connectors, Interconnects | Wire Strip Length | - |
| Wire Gauge or Range - mm² | - | Wire Gauge or Range - AWG | - |
| Voltage - UL | 300V | Voltage - IEC | 400V |
| Type | Header, Female Sockets | Torque - Screw | - |
| Termination Style | Solder | Series | Omnimate BL |
| Screw Size | - | Positions Per Level | 4 |
| Plug Wire Entry | - | Pitch | 0.200" (5.08mm) |
| Packaging | Bulk | Other Names | 1630730000-ND 281-3182 |
| Operating Temperature | -50°C ~ 100°C | Number of Positions | 4 |
| Number of Levels | 1 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Height | 0.797" (20.24mm) | Ingress Protection | - |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled | Header Orientation | Vertical |
| Features | Retention Latches | Detailed Description | 4 Position Terminal Block Header, Female Sockets 0.200" (5.08mm) Vertical Through Hole |
| Current - UL | 15A | Current - IEC | 23A |
| Contact Tail Length | 0.126" (3.20mm) | Contact Mating Finish | Tin |
| Contact Material | Copper Alloy | Color | Orange |
