695-1B
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 695-1B with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 695-1B with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 695-1B |
|---|---|
| Manufacturer | Wakefield-Vette |
| Description | HEATSINK FOR STUD MT DIODE BLACK |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.443 | $0.422 | $0.41 | $0.399 | $0.377 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.355 | $0.333 | $0.311 | $0.30 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 695-1B | Manufacturer | Wakefield-Vette |
|---|---|---|---|
| Description | HEATSINK FOR STUD MT DIODE BLACK | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 72740 pcs | Data sheet | Board Level Heat Sinks Catalog |
| Category | Fans, Thermal Management | Width | - |
| Type | Board Level | Thermal Resistance @ Natural | 18.00°C/W |
| Thermal Resistance @ Forced Air Flow | 5.20°C/W @ 400 LFM | Shape | - |
| Series | 695 | Power Dissipation @ Temperature Rise | 4.0W @ 72°C |
| Package Cooled | Stud Mounted Diode | Other Names | 345-1095 6951B |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 12 Weeks |
| Length | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.530" (13.46mm) | Diameter | 0.625" (15.88mm) ID, 1.330" (33.78mm) OD |
| Detailed Description | Heat Sink Stud Mounted Diode Aluminum 4.0W @ 72°C Board Level | Attachment Method | Bolt On |
