Home > Products > Sensors, Transducers > Strain Gauges > MMF003672

MMF003672

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MMF003672 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MMF003672
Manufacturer	Vishay Precision Group
Description	STRAIN GAUGE 350 OHM TEE 1=5PC
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 811 pcs
Reference Price (In US Dollars)	1 pcs	5 pcs	10 pcs	25 pcs	50 pcs
Reference Price (In US Dollars)	$54.731	$48.65	$45.609	$44.089	$42.569

Product parameter
Data sheet

Product parameter

Part Number	MMF003672	Manufacturer	Vishay Precision Group
Description	STRAIN GAUGE 350 OHM TEE 1=5PC	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	811 pcs	Data sheet	Standard Weldable Patterns Guide 062UT
Category	Sensors, Transducers	Width - Overall Pattern	0.225" (5.72mm)
Width - Overall	0.31" (7.9mm)	Width - Active	0.080" (2.03mm) per section
Strain Range	±3%	Series	CEA
Resistance Tolerance	±0.4%	Resistance	350 Ohms
Pattern Type	Tee Rosette	Other Names	1033-1001 CEA-06-062UT-350 CEA06062UT350 F003672
Operating Temperature	-100 ~ 350°F (-75 ~ 175°C)	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	12 Weeks	Length - Overall Pattern	0.205" (5.21mm)
Length - Overall	0.31" (7.9mm)	Length - Active	0.062" (1.57mm) per section
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Detailed Description	Tee Rosette Strain Gauge ±3% 0.062" (1.57mm) per section 0.080" (2.03mm) per section
