Home > Products > Sensors, Transducers > Strain Gauges > MMF003153

MMF003153

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MMF003153 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MMF003153
Manufacturer	Vishay Precision Group
Description	STRAIN GAUGE 350 OHM TEE 1=5PC
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 717 pcs
Reference Price (In US Dollars)	1 pcs	5 pcs	10 pcs	25 pcs	50 pcs
Reference Price (In US Dollars)	$58.547	$54.888	$53.059	$51.229	$50.314

Product parameter
Data sheet

Product parameter

Part Number	MMF003153	Manufacturer	Vishay Precision Group
Description	STRAIN GAUGE 350 OHM TEE 1=5PC	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	717 pcs	Data sheet	Standard Weldable Patterns Guide 125UT
Category	Sensors, Transducers	Width - Overall Pattern	0.365" (9.27mm)
Width - Overall	0.45" (11.4mm)	Width - Active	0.165" (4.19mm) per section
Strain Range	±5%	Series	CEA
Resistance Tolerance	±0.4%	Resistance	350 Ohms
Pattern Type	Tee Rosette	Other Names	1033-1006 CEA-06-125UT-350 CEA06125UT350 F003153
Operating Temperature	-100 ~ 350°F (-75 ~ 175°C)	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	12 Weeks	Length - Overall Pattern	0.325" (8.26mm)
Length - Overall	0.42" (10.7mm)	Length - Active	0.125" (3.18mm) per section
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Detailed Description	Tee Rosette Strain Gauge ±5% 0.125" (3.18mm) per section 0.165" (4.19mm) per section
