VPL36-700
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy VPL36-700 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy VPL36-700 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | VPL36-700 |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | XFRMR PWR 36V 0.7A CHASSIS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $5.941 | $4.389 | $4.052 | $3.917 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $3.808 | $3.754 | $3.714 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | VPL36-700 | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | XFRMR PWR 36V 0.7A CHASSIS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 9884 pcs | Data sheet | VPL36-700 |
| Category | Transformers | Weight | 1.3 lbs (589.7g) |
| Voltage - Secondary (Full Load) | 36V | Voltage - Primary | 115V, 230V |
| Voltage - Isolation | 3500Vrms | Type | Laminated Core |
| Termination Style | Wire Leads | Size / Dimension | 57.15mm L x 101.6mm W |
| Series | Chassis Mount: World Series™ | Secondary Winding(s) | Dual |
| Primary Winding(s) | Dual | Power - Max | 25.0 VA |
| Other Names | 237-1665 | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 49.22 mm |
| Current - Output (Max) | 700mA | Center Tap | No |
