SP-68
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SP-68 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SP-68 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SP-68 |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | TRANS 10K/10KCT 2.5K SPLIT AUDIO |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $5.881 | $4.48 | $4.13 | $3.99 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.92 | $3.78 | $3.64 | $3.50 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | SP-68 | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | TRANS 10K/10KCT 2.5K SPLIT AUDIO | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 9893 pcs | Data sheet | SP-68 |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 1000VRMS @ 1 Second | Turns Ratio - Primary:Secondary | 2.1:1 |
| Transformer Type | Audio Coupling | Termination Style | PC Pin |
| Size / Dimension | 0.410" L x 0.310" W (10.41mm x 7.87mm) | Series | Red-Spec |
| Return Loss | - | Power Level | 50mW |
| Packaging | Bulk | Other Names | 10644 237-1153 |
| Operating Temperature | - | Mounting Type | Through Hole |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Impedance - Secondary (Ohms) | 10k, 2.5k/2.5k |
| Impedance - Primary (Ohms) | 10k | Height - Seated (Max) | 0.465" (11.80mm) |
| Frequency Response | ±2dB | Frequency Range | 300Hz ~ 100kHz |
| DC Resistance (DCR) - Secondary | 565/650 Ohm | DC Resistance (DCR) - Primary | 1 kOhm |
| Approvals | - |
