F36-550
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy F36-550 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy F36-550 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | F36-550 |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | XFRMR LAMINATED THRU HOLE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $4.303 | $3.177 | $2.933 | $2.835 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.757 | $2.718 | $2.689 | $2.64 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | F36-550 | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | XFRMR LAMINATED THRU HOLE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 12923 pcs | Data sheet | F36-550 |
| Category | Transformers | Weight | 0.8 lb (362.87g) |
| Voltage - Secondary (Full Load) | Parallel 18V, Series 36V | Voltage - Primary | 115V |
| Voltage - Isolation | 2500Vrms | Type | Laminated Core |
| Termination Style | PC Pin | Size / Dimension | 57.15mm L x 47.63mm W |
| Series | Split Pack™, Class 2/3, F | Secondary Winding(s) | Dual |
| Primary Winding(s) | Single | Power - Max | 20 VA |
| Other Names | 237-1831 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 36.50mm |
| Current - Output (Max) | Parallel 1.1A, Series 550mA | Center Tap | No |
