C-80U
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy C-80U with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy C-80U with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | C-80U |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | FIXED IND 24MH 40A 25 MOHM CHASS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $64.688 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | C-80U | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | FIXED IND 24MH 40A 25 MOHM CHASS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 573 pcs | Data sheet | C-80U |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | -20%, +50% | Supplier Device Package | - |
| Size / Dimension | 4.562" L x 5.500" W (115.87mm x 139.70mm) | Shielding | Unshielded |
| Series | - | Ratings | - |
| Q @ Freq | - | Packaging | Bulk |
| Package / Case | Nonstandard | Other Names | 237-1786 |
| Operating Temperature | - | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | - |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 120Hz | Inductance | 24mH |
| Height - Seated (Max) | 5.312" (134.92mm) | Frequency - Self Resonant | - |
| Detailed Description | 24mH Unshielded Wirewound Inductor 40A 25 mOhm Nonstandard | DC Resistance (DCR) | 25 mOhm |
| Current Rating | 40A | Current - Saturation | - |
