AX97-30101
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AX97-30101 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy AX97-30101 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AX97-30101 |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | FIXED IND 100UH 1.5A 300 MOHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $0.661 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | AX97-30101 | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | FIXED IND 100UH 1.5A 300 MOHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 56842 pcs | Data sheet | AX97 Series Drawing |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.530" L x 0.370" W (13.46mm x 9.40mm) | Shielding | Unshielded |
| Series | AX97 | Ratings | - |
| Q @ Freq | - | Packaging | Bulk |
| Package / Case | Nonstandard | Operating Temperature | - |
| Mounting Type | Surface Mount | Material - Core | Ferrite |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 100kHz | Inductance | 100µH |
| Height - Seated (Max) | 0.232" (5.90mm) | Frequency - Self Resonant | - |
| Detailed Description | 100µH Unshielded Wirewound Inductor 1.5A 300 mOhm Max Nonstandard | DC Resistance (DCR) | 300 mOhm Max |
| Current Rating | 1.5A | Current - Saturation | - |
