TPCA8010-H(TE12L,Q
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TPCA8010-H(TE12L,Q with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TPCA8010-H(TE12L,Q with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TPCA8010-H(TE12L,Q |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET N-CH 200V 5.5A 8-SOPA |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | TPCA8010-H(TE12L,Q | Manufacturer | Toshiba Semiconductor and Storage |
|---|---|---|---|
| Description | MOSFET N-CH 200V 5.5A 8-SOPA | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5623 pcs | Data sheet | Mosfets Prod GuideTPCA8010-H |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 4V @ 1mA |
| Vgs (Max) | ±20V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | 8-SOP Advance (5x5) | Series | π-MOSV |
| Rds On (Max) @ Id, Vgs | 450 mOhm @ 2.7A, 10V | Power Dissipation (Max) | 1.6W (Ta), 45W (Tc) |
| Packaging | Tape & Reel (TR) | Package / Case | 8-PowerVDFN |
| Other Names | TPCA8010HTE12LQTR | Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 600pF @ 10V |
| Gate Charge (Qg) (Max) @ Vgs | 10nC @ 10V | FET Type | N-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Drain to Source Voltage (Vdss) | 200V | Detailed Description | N-Channel 200V 5.5A (Ta) 1.6W (Ta), 45W (Tc) Surface Mount 8-SOP Advance (5x5) |
| Current - Continuous Drain (Id) @ 25°C | 5.5A (Ta) |
