TLP705A(F)
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TLP705A(F) with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TLP705A(F) with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TLP705A(F) |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | OPTOISO 5KV GATE DRIVER 6SDIP GW |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | 300 pcs |
|---|---|---|---|---|---|
| $0.592 | $0.481 | $0.37 | $0.333 | $0.296 | |
| 500 pcs | 1000 pcs | 2500 pcs | 5000 pcs | ||
| $0.251 | $0.207 | $0.197 | $0.192 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | TLP705A(F) | Manufacturer | Toshiba Semiconductor and Storage |
|---|---|---|---|
| Description | OPTOISO 5KV GATE DRIVER 6SDIP GW | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 98481 pcs | Data sheet | TLP705A |
| Category | Isolators | Voltage - Supply | 10 V ~ 30 V |
| Voltage - Isolation | 5000Vrms | Voltage - Forward (Vf) (Typ) | 1.57V |
| Technology | Optical Coupling | Supplier Device Package | 6-SDIP |
| Series | - | Rise / Fall Time (Typ) | 35ns, 15ns |
| Pulse Width Distortion (Max) | 50ns | Propagation Delay tpLH / tpHL (Max) | 170ns, 170ns |
| Packaging | Tube | Package / Case | 6-SOIC (0.268", 6.80mm Width) |
| Other Names | TLP705A (F) TLP705AF |
Operating Temperature | -40°C ~ 100°C |
| Number of Channels | 1 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Detailed Description | 600mA Gate Driver Optical Coupling 5000Vrms 1 Channel 6-SDIP | Current - Peak Output | 600mA |
| Current - Output High, Low | 400mA, 400mA | Current - DC Forward (If) (Max) | 25mA |
| Common Mode Transient Immunity (Min) | 20kV/µs | Approvals | cUL, UL |
