TLP2631TP1F
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TLP2631TP1F with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TLP2631TP1F with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TLP2631TP1F |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | OPTOISO 2.5KV 2CH OPEN COLL 8SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1500 pcs | ||||
|---|---|---|---|---|---|
| $0.355 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | TLP2631TP1F | Manufacturer | Toshiba Semiconductor and Storage |
|---|---|---|---|
| Description | OPTOISO 2.5KV 2CH OPEN COLL 8SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 56082 pcs | Data sheet | TLP2631 |
| Category | Isolators | Voltage - Supply | 4.5 V ~ 5.5 V |
| Voltage - Isolation | 2500Vrms | Voltage - Forward (Vf) (Typ) | 1.65V |
| Supplier Device Package | 8-SMD | Series | - |
| Rise / Fall Time (Typ) | 30ns, 30ns | Propagation Delay tpLH / tpHL (Max) | 75ns, 75ns |
| Packaging | Tape & Reel (TR) | Package / Case | 8-SMD, Gull Wing |
| Output Type | Open Collector, Schottky Clamped | Other Names | TLP2631 (TP1,F) TLP2631(TP1,F) TLP2631TP1FTR |
| Operating Temperature | -40°C ~ 85°C | Number of Channels | 2 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inputs - Side 1/Side 2 | 2/0 |
| Input Type | DC | Detailed Description | Logic Output Optoisolator 10MBd Open Collector, Schottky Clamped 2500Vrms 2 Channel 1kV/µs CMTI 8-SMD |
| Data Rate | 10MBd | Current - Output / Channel | 16mA |
| Current - DC Forward (If) (Max) | 20mA | Common Mode Transient Immunity (Min) | 1kV/µs |
