TLP185(GR-TPL,SE
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TLP185(GR-TPL,SE with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TLP185(GR-TPL,SE with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TLP185(GR-TPL,SE |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | OPTOISO 3.75KV TRANS 6-SO 4 LEAD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | 6000 pcs | 15000 pcs | 30000 pcs | 75000 pcs |
|---|---|---|---|---|---|
| $0.042 | $0.04 | $0.036 | $0.034 | $0.031 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | TLP185(GR-TPL,SE | Manufacturer | Toshiba Semiconductor and Storage |
|---|---|---|---|
| Description | OPTOISO 3.75KV TRANS 6-SO 4 LEAD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 755862 pcs | Data sheet | TLP185(SE |
| Category | Isolators | Voltage - Output (Max) | 80V |
| Voltage - Isolation | 3750Vrms | Voltage - Forward (Vf) (Typ) | 1.25V |
| Vce Saturation (Max) | 300mV | Turn On / Turn Off Time (Typ) | 3µs, 3µs |
| Supplier Device Package | 6-SO, 4 Lead | Series | - |
| Rise / Fall Time (Typ) | 2µs, 3µs | Packaging | Tape & Reel (TR) |
| Package / Case | 6-SOIC (0.179", 4.55mm Width), 4 Leads | Output Type | Transistor |
| Other Names | TLP185(GR-TPL,SE(T TLP185(GR-TPL,SETR TLP185(GR-TPLSE(TTR TLP185(GR-TPLSE(TTR-ND TLP185(GR-TPLSETR TLP185GRTPLSE TLP185GRTPLSET |
Operating Temperature | -55°C ~ 110°C |
| Number of Channels | 1 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Type | DC | Detailed Description | Optoisolator Transistor Output 3750Vrms 1 Channel 6-SO, 4 Lead |
| Current Transfer Ratio (Min) | 100% @ 5mA | Current Transfer Ratio (Max) | 300% @ 5mA |
| Current - Output / Channel | 50mA | Current - DC Forward (If) (Max) | 50mA |
