SSM6J505NU,LF
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SSM6J505NU,LF with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SSM6J505NU,LF with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SSM6J505NU,LF |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET P CH 12V 12A UDFN6B |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | ||||
|---|---|---|---|---|---|
| $0.069 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SSM6J505NU,LF | Manufacturer | Toshiba Semiconductor and Storage |
|---|---|---|---|
| Description | MOSFET P CH 12V 12A UDFN6B | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 293941 pcs | Data sheet | SSM6J505NU |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 1V @ 1mA |
| Vgs (Max) | ±6V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | 6-UDFNB (2x2) | Series | U-MOSVI |
| Rds On (Max) @ Id, Vgs | 12 mOhm @ 4A, 4.5V | Power Dissipation (Max) | 1.25W (Ta) |
| Packaging | Tape & Reel (TR) | Package / Case | 6-WDFN Exposed Pad |
| Other Names | SSM6J505NU,LF(B SSM6J505NU,LF(T SSM6J505NULF SSM6J505NULFTR |
Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 2700pF @ 10V |
| Gate Charge (Qg) (Max) @ Vgs | 37.6nC @ 4.5V | FET Type | P-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 1.2V, 4.5V |
| Drain to Source Voltage (Vdss) | 12V | Detailed Description | P-Channel 12V 12A (Ta) 1.25W (Ta) Surface Mount 6-UDFNB (2x2) |
| Current - Continuous Drain (Id) @ 25°C | 12A (Ta) |
