Home > Products > RF/IF and RFID > RF Antennas > FXP543.A.07.A.001

FXP543.A.07.A.001

FXP543.A.07.A.001

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FXP543.A.07.A.001 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	FXP543.A.07.A.001
Manufacturer	Taoglas
Description	RF ANT 2.4GHZ/5.8GHZ FLAT PATCH
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 5988 pcs
Reference Price (In US Dollars)	1 pcs	100 pcs	500 pcs
Reference Price (In US Dollars)	$6.695	$6.472	$6.249

Product parameter
Data sheet

Product parameter

Part Number	FXP543.A.07.A.001	Manufacturer	Taoglas
Description	RF ANT 2.4GHZ/5.8GHZ FLAT PATCH	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	5988 pcs	Data sheet	FXP543.A.07.A.001 Specification
Category	RF/IF and RFID	VSWR	-
Termination	Cable (100mm) - U.FL (3)	Series	Venti
Return Loss	-10dB, -9dB	Power - Max	5W
Packaging	Bulk	Other Names	931-1417
Number of Bands	2	Mounting Type	Adhesive
Manufacturer Standard Lead Time	6 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Height (Max)	0.006" (0.15mm)
Gain	2.96dBi, 5.16dBi	Frequency Range	2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.85GHz
Frequency Group	UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz)	Frequency (Center/Band)	2.4GHz, 5.8GHz
Features	-	Detailed Description	2.4GHz, 5.8GHz Wi-Fi Flat Patch RF Antenna 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.85GHz 2.96dBi, 5.16dBi Cable (100mm) - U.FL (3) Adhesive
Applications	Wi-Fi	Antenna Type	Flat Patch
