TTC-170
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TTC-170 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TTC-170 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TTC-170 |
|---|---|
| Manufacturer | Tamura |
| Description | TRANSF TELE COUP 600:600 0MADC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.646 | $2.056 | $2.00 | $1.722 | ||
| 100 pcs | 250 pcs | 500 pcs | 1710 pcs | ||
| $1.645 | $1.611 | $1.583 | $1.556 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | TTC-170 | Manufacturer | Tamura |
|---|---|---|---|
| Description | TRANSF TELE COUP 600:600 0MADC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 21648 pcs | Data sheet | TTC-170 |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 1500VRMS @ 1 Minute | Turns Ratio - Primary:Secondary | 1:1 |
| Transformer Type | Data/Voice Coupling | Termination Style | PC Pin |
| Size / Dimension | 0.528" L x 0.512" W (13.40mm x 13.00mm) | Series | TTC |
| Return Loss | - | Power Level | - |
| Packaging | Bulk | Other Names | MT11108 MT4140 TTC170 |
| Operating Temperature | 0°C ~ 70°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 26 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | 1.5dB Max @ 1kHz |
| Impedance - Secondary (Ohms) | 600 | Impedance - Primary (Ohms) | 600 |
| Height - Seated (Max) | 0.421" (10.70mm) | Frequency Response | ±0.5dB |
| Frequency Range | 300Hz ~ 3.5kHz | DC Resistance (DCR) - Secondary | 61 Ohm |
| DC Resistance (DCR) - Primary | 47 Ohm | Approvals | CSA-C22.2 No. 66-M1988, UL1459 |
