Home > Products > Transformers > Power Transformers > PL56-24-130B

PL56-24-130B

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PL56-24-130B with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	PL56-24-130B
Manufacturer	Tamura
Description	XFRMR LAMINATED 56VA THRU HOLE
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 5493 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
Reference Price (In US Dollars)	$7.699	$6.794	$6.567	$5.888	$5.662

Product parameter
Data sheet

Product parameter

Part Number	PL56-24-130B	Manufacturer	Tamura
Description	XFRMR LAMINATED 56VA THRU HOLE	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	5493 pcs	Data sheet	PL56-xx-130B
Category	Transformers	Weight	-
Voltage - Secondary (Full Load)	Parallel 12V, Series 24V	Voltage - Primary	115V, 230V
Voltage - Isolation	3500Vrms	Type	Laminated Core
Termination Style	PC Pin	Size / Dimension	76.20mm L x 64.00mm W
Series	PL56-xx-130B	Secondary Winding(s)	Dual
Primary Winding(s)	Dual	Power - Max	56 VA
Other Names	MT3130 PL56-24 PL56-24(BOX) PL56-24(BULK) PL5624130B	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	26 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Height - Seated (Max)	48.50mm
Current - Output (Max)	Parallel 4.66A, Series 2.33A	Center Tap	No
