MET-43
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MET-43 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MET-43 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MET-43 |
|---|---|
| Manufacturer | Tamura |
| Description | TRANSFORMER 120CT:3.2 10.0MADC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 550 pcs | ||||
|---|---|---|---|---|---|
| $2.796 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | MET-43 | Manufacturer | Tamura |
|---|---|---|---|
| Description | TRANSFORMER 120CT:3.2 10.0MADC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10929 pcs | Data sheet | MET-43 |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 500VRMS @ 1 Minute | Turns Ratio - Primary:Secondary | 6.12:1 |
| Transformer Type | Data/Voice Coupling | Termination Style | PC Pin |
| Size / Dimension | 0.409" L x 0.310" W (10.40mm x 7.87mm) | Series | MET |
| Return Loss | - | Power Level | 50mW |
| Packaging | Bulk | Operating Temperature | -20°C ~ 85°C |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 26 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Impedance - Secondary (Ohms) | 3.2 |
| Impedance - Primary (Ohms) | 120CT | Height - Seated (Max) | 0.465" (11.80mm) |
| Frequency Response | ±2dB | Frequency Range | 300Hz ~ 100kHz |
| DC Resistance (DCR) - Secondary | 700 mOhm | DC Resistance (DCR) - Primary | 13 Ohm |
| Approvals | - |
