2DM180506CM
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2DM180506CM with confidence from Components-World.HK, 1 Year Warranty
Dowload 2DM180506CM Details in PDFSee Product Specifications for product details.
Buy 2DM180506CM with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2DM180506CM |
|---|---|
| Manufacturer | Tamura |
| Description | IC N-CH GATE DRIVER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | ||
|---|---|---|---|---|---|
| $33.81 | $32.03 | $28.471 | |||
| 25 pcs | 50 pcs | 100 pcs | |||
| $26.692 | $25.802 | $24.912 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2DM180506CM | Manufacturer | Tamura |
|---|---|---|---|
| Description | IC N-CH GATE DRIVER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1353 pcs | Data sheet | 2DM180506CM DatasheetDM Series Product Info |
| Category | Integrated Circuits (ICs) | Voltage - Supply | 15 V ~ 24 V |
| Supplier Device Package | 0502 | Series | - |
| Rise / Fall Time (Typ) | - | Packaging | Tray |
| Package / Case | 34-DIP Module, 31 Leads | Other Names | 2DM180506CM-ND 9-2DM180506CMZY MT7430 |
| Operating Temperature | -30°C ~ 85°C (TA) | Number of Drivers | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 24 Weeks | Logic Voltage - VIL, VIH | 0.8V, 2V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Type | - |
| Gate Type | N-Channel MOSFET | Driven Configuration | Half-Bridge |
| Detailed Description | Half-Bridge Gate Driver IC 0502 | Current - Peak Output (Source, Sink) | - |
| Channel Type | Independent |
