HM41-11510
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HM41-11510 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HM41-11510 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HM41-11510 |
|---|---|
| Manufacturer | TT Electronics |
| Description | TRANSFORMER GATE DRV MAGN TOROID |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | HM41-11510 | Manufacturer | TT Electronics |
|---|---|---|---|
| Description | TRANSFORMER GATE DRV MAGN TOROID | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 4020 pcs | Data sheet | HM41 Model |
| Category | Transformers | Turns Ratio - Primary:Secondary | 15:15:10 |
| Transformer Type | Gate Drive | Size / Dimension | 0.945" L x 0.551" W (24.00mm x 14.00mm) |
| Series | HM41 | Packaging | Bulk |
| Other Names | 987-1201 HM4111510 |
Operating Temperature | -25°C ~ 85°C |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Inductance | 470µH |
| Height - Seated (Max) | 0.787" (20.00mm) | Energy Time (E.T.) | 98V µS |
