Home > Products > Power Supplies - Board Mount > DC DC Converters > PXB15-12D12/N

PXB15-12D12/N

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PXB15-12D12/N with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	PXB15-12D12/N
Manufacturer	TDK-Lambda Americas, Inc.
Description	DC DC CONVERTER +/-12V 15W
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1546 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$19.904

Product parameter
Data sheet

Product parameter

Part Number	PXB15-12D12/N	Manufacturer	TDK-Lambda Americas, Inc.
Description	DC DC CONVERTER +/-12V 15W	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1546 pcs	Data sheet	PXB15-xxDxx Datasheet PXB Series Overview
Category	Power Supplies - Board Mount	Voltage - Output 3	-
Voltage - Output 2	-12V	Voltage - Output 1	12V
Voltage - Isolation	1.6kV	Voltage - Input (Min)	9V
Voltage - Input (Max)	18V	Type	Isolated Module
Size / Dimension	1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)	Series	PXB
Power (Watts)	15W	Packaging	Bulk
Package / Case	6-DIP Module	Other Names	PXB1512D12/N
Operating Temperature	-40°C ~ 85°C	Number of Outputs	2
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	16 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Features	Remote On/Off, OCP, OVP, SCP	Efficiency	87%
Detailed Description	Isolated Module DC DC Converter 2 Output 12V -12V 625mA, 625mA 9V - 18V Input	Current - Output (Max)	625mA, 625mA
Control Features	Enable, Active Low	Applications	ITE (Commercial)
